    Sanitary Quick Installation Ball Valve With Low Friction Coefficient

    Ask Lasest Price
    Brand Name : FABIA
    Model Number : 1/8 inch ~ 36 inch
    Certification : ISO9001,CE,CCS,DNV
    Price : Negotiable
    Delivery Time : 15-30 work days
    Payment Terms : L/C, D/A, D/P, T/T, MoneyGram, Western Union
    Supply Ability : 100-1000 set per week
    • Product Details
    • Company Profile

    Sanitary Quick Installation Ball Valve With Low Friction Coefficient

    FABIA Sanitary Quick Installation Ball Valve With Low Friction Coefficient


    1. Description:


    Sanitary grade fast ball loading valve is mainly used in oil and natural gas pipeline engineering.


    2. Specification:


    FABIA Valve Parameter List
    Valve type:Sanitary Quick Installation Ball Valve With Low Friction Coefficient
    Size:1/8 inch ~ 8 inch
    Material:WCB,Q235B,2507,A105,CF8(304),CF8M(316),CF3M (316L),CF3(304L),PVC,ZG1Cr18Ni9Ti,ZG1Cr18Ni12Mo2Ti
    Connection type:Welded connection/flange connection/thread connection/clamp connection
    Driving model:Manual/Worm gear drive/Pneumatic/Electric
    Pressure rating:PN1.0~PN16,ANSI CLASS 150-900,JIS10-20K;
    Temperature:-196℃~540℃
    Model:FB-Q..........

    3. Features:


    • Valve seat designed ball valv manufacturing experience has a very low coefficient of friction, and the operating force is small.
    • Valve stem has a flight-proof structure, set relevant steps below the valve stem, from the inside of the valve body and then installed to the valve stem, so as to prevent the valve stem from flying out.
    • Sanitary ball valve can prevent static electricity.
    • Antistatic spring set between the ball and the valve body or stem can export the static electricity generated by the switch during the operation.
    • Good fire resistance, its excellent fire resistance design, after the fire, the leakage parts are designed into flexible graphite filler or stainless steel graphite, which well meets the requirements of fire resistance, but also in line with the provisions of API6FA and API607.
    • Connection of anti-dislocation design, this sanitary quick installation ball valve in order to prevent the valve switch from being misoperated, the switch is fully open, fully closed position is provided with a locking hole to ensure that the valve is in the correct position.
    • Structure of the support plate of the sanitary ball valve greatly improves the service life of the valve and also reduces the operating torque of the valve. The service life of the valve is greatly extended.
